Bluetooth Mesh Touch Thermostat

BLE Mesh

This device is a smart home touch screen wall thermostat that works with Bluetooth mesh digital signal with the host or scenario switch, allowing you to remote access control with wifi, 3G, 4G, and 5G signal. It works with fan coil units' central air-conditioning(FCU Aircon) to simplify the installation. This intelligent home central Air-conditioning fan coil unit thermostat has three-speed options, Environment Temperature Indication, Child lock function, low energy, and no wifi design. This device can be customized based on your chipsets' solutions, such as Zigbee and wifi.

Overview

Parameter

Basic

Name: BLE Mesh Touch Screen Thermostat Model: BLG and BLE Apple to: Smart hotel, Smart business building, School, Museum, Government Building, Law Court, etc.
Material: Plastic+metal
Operation environment: Temperature:-0~50℃, Humidity:10%~95% Material: Plastic (PC) + ABS Flame Retardant + Tempered Glass Weight: 180g
Size：86 mm * 86 mm * 23 mm
Installation hole spacing: 60mm (standard)

Technic information

Communication: BLE Mesh
Power supply: AC 220V 50/60Hz
Temperature settings: 5℃ — 35℃

Temperature Control Accuracy: ±1℃ Antenna type: Built-in Unidirectional Antenna
Support gateway: All Geeklink BLE Mesh Host or Gateway
Support relay： support relay function extend the signal for 200 meters

Software

Support: Android 6.0 /IOS 10 or above
App Name: Geeklink Smart Partner/Brilliant Home
